Isuzu garbage sorting and collection vehicle: an efficient waste management solution
-Isuzu is an efficient and reliable vehicle designed for the effective collection, transportation and disposal of solid waste. Based on the rugged Isuzu KV600 chassis, the truck combines a compact size and strong performance, making it ideal for both urban and suburban waste management operations.
With a total weight of 8,280 kg and a wheelbase of 3,360 mm, the truck has excellent mobility in a small space. The cab has hydraulic power steering and can accommodate one driver and two passengers, ensuring easy operation and comfort during long working hours. Post-dumping design and self-loading capacity simplify the waste collection process, making it a reliable option for municipalities and private contractors.
With an advanced Isuzu 4KH1CN6HB engine, this truck meets the Euro 6 emission standard and provides environmentally friendly operation without compromising performance.
product superiority
Reliable engine and gearbox
At the core of the truck is the Isuzu 4KH1CN6HB engine, a 2.999-liter in-line four-cylinder engine with 132 HP and 290 rpm at 1,500 N · m. This water-cooled mid-cooled turbocharged engine ensures consistent and powerful performance in demanding garbage collection tasks.
-Isuzu MSB Manual Transmission-5 forward gears and 1 reverse gear for precise control and smooth operation, ensuring adaptation to various terrain and work loads.
Durable and spacious upper body
The truck is equipped with 5m³ waste containers made from Q235B carbon steel and is known for its high strength and durability. The side walls (4 mm thickness) and the bottom plate (6mm thickness) provide strong protection against wear during daily operations.
The container is designed for efficiency improvement, including a rear automatic bomb loader structure and a post-dumping system to simplify waste treatment and disposal. Hydraulic cylinders, from top Chinese brands, ensure reliable, fast operation, bucket rise time 20 seconds and bucket down time 80 seconds.
Compact and efficient design
The overall size of 5,9952,2602,650 mm, the truck has a compact design ideal for driving in narrow streets and crowded urban areas. Its 7.50R16 tires provide excellent traction and stability, while the 42-drive configuration has enhanced maneuverability and efficiency.
The lightweight truck trim weight of 4,600 kg ensures the optimal payload capacity and is suitable for medium waste collection operations.
Eco-friendly and cost-efficient operation
Conference Euro 6 emission standards, Isuzu garbage truck ensures fuel efficiency while reducing environmental impact. The hydraulic power steering system minimizes operator fatigue and improves long shifts.
The combination of low operating costs, reliable performance, and durable construction makes the truck a practical and cost-effective solution for modern waste management needs.
-The Isuzu dump truck provides the perfect combination of power, durability, and efficiency for waste management operations. With its advanced engine, rugged structure and user-friendly features, it is the perfect partner for municipalities and contractors to streamline the waste collection process.
size of product:
same as | |
Brand / model | Isuzu / GDT05QL132L6 |
Optical drive type | 42 left |
outline dimension (Length x wide x high) | 5,9952,2602,650 (mm) |
gross vehicle load | 8,280kg |
The curb weight | 4,600kg |
wheel base | 3,360mm |
Chassis design | Isuzu KV600 |
cabin | Hydraulic power steering type. 1 driver + 2 passengers |
Drive wheel (tyres) | 4 + 2 plus 7 spare tires (total of XNUMX tires) |
Tire size | 7.50R16 |
engine | |
Brand / model | Isuzu / 4KH1CN6HB |
type | In-line 4-cylinder, 4-stroke direct injection, water-cooled, medium-cooled turbocharging |
gression | 2.999L |
nominal capacity | 132 hp (97 kW) @ 2,900 rpm |
Peak torque | 290 Newton meters @1,500rpm |
effluent standard | Euro 6 |
T transfer | |
Brand / model | isuzu /MSB |
type | diesel oil |
operate | user's manual |
Speed number | 5F + 1R |
the upper part of the body | |
capacity | 5m3 |
material | Q235B carbon steel |
thickness | 4mm and 6mm |
Loading mode | The rear is automatically filled |
The direction of dumping | behind |
fluid cylinder | China's top brand |
Shovel up time | ≤20s |
Shovel stop time | 80s 80s |
